BASF CL-750 is particularlyappropriate for use in vapor phasechloride traps in catalytic reformingprocesses where optimum HCladsorption capacity and minimizationof polymer (“gum”) formation isdesirable. The high macroporosity ofBASF CL-750 improves diffusion ratesto assure high HCl adsorptioncapacity.
Liquid naphtha reformate streamsoften contain sufficientamounts of HClwhich cause corrosion and NH4Clplugging problems in heat exchangers,pumps, compressors and stabilizer towers. BASF CL-750 is an excellentHCl scavenger for these streams atboth ambient and elevatedtemperatures. The use of BASF CL-750chloride adsorbent allows continuousoperation without the problemsassociated with water washing ofchloride deposits in process equipment.
With its superior adsorption capacityand high porosity, CL-750 is appropriatefor the removal of HCl and free chlorideions from a variety of vapor and liquidphase streams in numerous petrochemicalproduction processes
2000 lb super sacks
330 lb steel drums
Typical Chemical Composition (%) | |
Al2O3+ surface modifier (inorganic, non-toxic) | 95.5 |
SiO2 | 0.015 |
LOI (1000ºC) | 4.0 |
Typical Physical Properties | |
Total Pore Volume, cc/g | 0.50 |
Bulk Density, lbs/ft3(kg/m3) | 47.5 (760) |
Crush Strength, (5 mesh eq), lbsf(kgf) | 30 (14) |
